Through Holes

Part of Cap

Perforations in the cap that allow fluid to pass through.

Dimensions

Through holes must be offset by 250 µm from the edge of the molded or machined microfeature.

Top view of the reference device with the through hole in the cap highlighted. — Top view

Bar scale showing 2 cm as 18.182% of the figure's width.

Close-up of the through hole in the cap. The through hole is offset by 250 µm from the edge of a molded microfeature.

Bar scale showing 700 µm as 21.477% of the figure's width.
